motor
Engine Type
V2, four-stroke
Displacement
1200.0 ccm (73.22 cubic inches)
Engine Details
Evolution engine
Power
68.0 HP (49.6 kW )) @ 6000 RPM
Torque
96.0 Nm (9.8 kgf-m or 70.8 ft.lbs) @ 5750 RPM
Bore x Stroke
88.9 x 96.8 mm (3.5 x 3.8 inches)
Fuel System
Injection. Electronic Sequential Port Fuel Injection (ESPFI)
Clutch
Multi-plate with diaphragm spring in oil bath
Driveline
Chain, 34/57 ratio primary drive
Fuel Consumption
4.90 litres/100 km (20.4 km/l or 48.00 mpg)
Greenhouse Gases
113.7 CO 2 g/km. (CO2 - Carbon dioxide emission)
Exhaust System
Chrome, staggered, shorty exhaust with dual mufflers
sasi
Trail
145 mm (5.7 inches)
Front Suspension
Telescopic fork
Rear Suspension
Twin shocks
Front Brakes
Single disc. Optional ABS. Two-piston calliper.
Rear Brakes
Single disc. Optional ABS. Two-piston calliper.
Wheels
Black/Silver, Split 5-Spoke Cast Aluminum
boyut
Overall Length
2210 mm (87.0 inches)
Seat Height
705 mm (27.8 inches) If adjustable, lowest setting.
Ground Clearance
95 mm (3.7 inches)
Dry Weight
263.0 kg (579.8 pounds)
Power/Weight Ratio
0.2586 HP/kg
Carrying Capacity
Saddle bags
Fuel Capacity
17.03 litres (4.50 US gallons)
Oil Capacity
2.60 litres (2.75 US quarts)
diger
Color Options
Vivid Black, Billet Silver, Bonneville Blue/Phatom Blue, Mysterious Red Sunglo/Velocity Red Sunglo, Black Hills Gold/Black Quartz
Light
High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (optional)
Instruments
Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights
